Aruba AS-100 (CN) DBSC 11n 1×1 BLE Snsr
JW794A Specification |
|
|
Product Model |
Aruba AS-100 (CN) DBSC 11n 1×1 BLE Sensor |
|
Radio type |
Indoor, dual-band client radio, 5 GHz or 2.4 GHz 802.11a/b/g/n 1×1 |
|
Data rate |
Maximum data rate of 72.2 Mbps (HT20) or 150 Mbp (HT40) |
|
Supported frequency bands |
Country-specific restrictions apply: – 2.400 GHz to 2.4835 GHz – 5.150 GHz to 5.250 GHz (U-NII-1) – 5.250 GHz to 5.350 GHz (U-NII-2) – 5.470 GHz to 5.725 GHz (U-NII-2E) – 5.725 GHz to 5.850 GHz (U-NII-3 / ISM) |
|
Supported radio technologies |
– 802.11b: Direct-sequence spread-spectrum (DSSS) – 802.11a/g/n: Orthogonal frequency-division multiplexing (OFDM) |
|
Supported modulation types |
– 802.11b: BPSK, QPSK, CCK – 802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM |
|
Transmit power (conducted) |
10 dBm – Excludes antenna gain (2.3 dBi/3.7 dBi for 2.4 GHz/5 GHz) – Power may be restricted to comply with local regulatory requirements |
|
Supported data rates (Mbps) |
– 802.11b: 1, 2, 5.5, 11 – 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 – 802.11n: 6.5 to 150 (MCS0 to MCS7) |
|
Other Interfaces |
• AC power interface, supporting multiple region-specific plugs – Plug shipping with unit defined by part number – AC power voltage range: 90V – 265V – AC power frequency range: 47 Hz – 63 Hz • USB 2.0 device interface (micro-B type connector) for DC power (5V, USB standard) • On/off push-button power switch • Bluetooth Low Energy (BLE) radio – Up to 4dBm transmit power (class 2) and -94 dBm receive sensitivity – Integrated antenna, 0.3 dBi gain • Visual indicator for system status (bi-color LED) • Reset button: factory reset (during device power up), LED on/off toggle (during operation) • Serial console interface (custom, compatible with AP-CBL-SER) • Kensington security slot |
|
Power |
• Maximum (worst-case) power consumption: 1.6W (from USB) or 2.2W (from AC) • When both power sources are available, DC (USB) power takes priority (no current drawn from AC) |
|
Environmental |
• Operating: – Temperature: 0° C to +50° C (+32° F to +122° F) – Humidity: 5% to 95% non-condensing • Storage and transportation: – Temperature: -40° C to +70° C (-40° F to +158° F) |
|
Dimensions/weight (unit, excluding mount accessories, AC plug) |
– 80 mm x 48 mm x 29 mm (W x D x H) – 65g |
